Prolumia Prodisc, Ø348, emergency, 13W, 3000K/4000K switchable
| Serie: | Prolumia LED Prodisc |
| Art. nr: | 40009322 |
| EAN: | 8720615508273 |
| User unit: | 1 PCE |
| Brand: | Prolumia |
| Type: | 40009322 |
| Manufacturer number: | 40009322 |
- Polycarbonate housing
- Available with built in microwave- / light sensor and / or emergency function
- Luminaires with and without sensor can be combined as master / slave (wired)
Gross price (excl. VAT)
€ 145,50 Per 1 piece
€ 145,50 Per 1 piece
Raymond Sakko
Customer service
Do you have any questions?
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Description
The LED Prodisc luminaire provides high energy savings (> 70%) through intelligent lighting management with presence detectors. Safety is the prime consideration in stairwells and hallways. They must be properly illuminated with enough brightness without reflections to ensure safe passage. The LED Prodisc is highly suitable for this.Product features
| Subgroup | LED Prodisc ⌀ 348 mm switchable |
| Brand | Prolumia |
| Suitable for wall mounting | Yes |
| Suitable for wall mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for ceiling mounting | Yes |
| Suitable for built-in mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for light line configuration | No |
| Suitable for workplace according to EN 12464-1 | No |
| Lamp type | LED not exchangeable |
| With light source | Yes |
| Lamp holder | Other |
| Housing material | Plastic |
| Surface protection housing | Other |
| Housing colour | White |
| Material cover | Plastic, opal |
| Type of grid | None |
| Voltage type | AC |
| Nominal voltage | 220 - 240 Volt |
| Type of control gear | LED operating device current-controlled |
| With control gear | Yes |
| Exchangeable control gear | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DALI-2 | No |
| Dimming DMX | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming DSI | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off (trailing edge) | No |
| Dimming phase cut-on (leading edge) | No |
| Dimming programmable | No |
| Dimming potentiometer (integrated) | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| No dim function | Yes |
| Dimming depending on control gear | No |
| Light distributor | Diffuser lens/optic/panel |
| Light distribution | Symmetric |
| Beam angle | > 80° - Extreme wide beam |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Light outlet | Direct |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Rated lifetime L70/B50 at 25 °C | 175000 Hour |
| Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) | 90 Percentage |
| Failure rate at median useful life of 50,000 h at 25 °C ambient (tq) | 50 Percentage |
| Rated life time L80/B10 at 25 °C | 100000 Hour |
| Rated life time L90/B50 at 25 °C | 50000 Hour |
| Degree of protection (IP) | IP44 |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 64 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 128 |
| Impact strength | IK10 |
| Protection class according to IEC 61140 | II |
| Emergency power supply integrated | Yes |
| Rated ambient temperature according to IEC 62722-2-1 | -20 - 50 Degrees celsius |
| Suitable for emergency lighting | Yes |
| With movement sensor | No |
| Luminaire efficacy | 100 Lumen/Watt |
| Rated luminous flux according to IEC 62722-2-1 | 1300 Lumen |
| With light sensor | No |
| Covering of the luminaire with thermally insulating material possible | No |
| With air slots | No |
| Colour of light according to EN 12464-1 | Neutral white 3300-5300 K |
| Max. system power | 13 Watt |
| Colour of light | White |
| Colour temperature | 3000 - 4000 Kelvin |
| Colour rendering index CRI | 80-89 |
| Power factor | 0.9 |
| Height/depth | 100 Millimetre |
| Outer diameter | 348 Millimetre |
| Type of wiring | Ending |
| Number of poles | 2 |
| Connection type | Push-in clamp |
| Colour of light adjustable | Positions |
| Luminous flux adjustable | Positions |
| Beam angle adjustable | No |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
+ View all specifications
- Hide additional specifications
