Prolumia Pro-Space,built-in,round125mm,11W,840Lm,4200K,Ra>80,120,dim(triac)
| Serie: | Prolumia LED Pro-Space |
| Art. nr: | 40004226 |
| EAN: | 8720604742909 |
| User unit: | 1 PCE |
| Brand: | Prolumia |
| Type: | 40004226 |
| Manufacturer number: | 40004226 |
- Aluminium housing with polycarbonate shield
- Sleek, trimless design
- Very low installation depth
- Waterproof (IP66) and impact resistant (IK08)
Gross price (excl. VAT)
€ 68,00 Per 1 piece
€ 68,00 Per 1 piece
Stock on request
Raymond Sakko
Customer service
Do you have any questions?
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Description
The LED Pro-Space is a sleek and timeless recessed fixture, with a very low installation depth. Due to its trimless design it integrates flawlessly in any ceiling, while the IP66 classification enables use in humid places without difficulty.Product features
| Subgroup | LED Pro-Space round ⌀ 125 mm |
| Brand | Prolumia |
| Suitable for wall mounting | Yes |
| Suitable for wall mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for ceiling mounting | Yes |
| Suitable for built-in mounting | Yes |
| Suitable for surface mounting | No |
| Suitable for light line configuration | No |
| Suitable for workplace according to EN 12464-1 | No |
| Lamp type | LED not exchangeable |
| With light source | Yes |
| Lamp holder | Other |
| Housing material | Aluminium |
| Surface protection housing | Other |
| Housing colour | White |
| Material cover | Plastic, opal |
| Type of grid | None |
| Voltage type | AC |
| Nominal voltage | 220 - 240 Volt |
| Nominal current | 500 Milliampere |
| Type of control gear | LED operating device current-controlled |
| With control gear | Yes |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming DSI | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off (trailing edge) | Yes |
| Dimming phase cut-on (leading edge) | No |
| Dimming programmable | No |
| Dimming potentiometer (integrated) | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| No dim function | No |
| Dimming depending on control gear | Yes |
| Light distributor | Diffuser lens/optic/panel |
| Light distribution | Symmetric |
| Beam angle | > 80° - Extreme wide beam |
| Colour consistency (McAdam ellipse) | SDCM4 |
| Light outlet | Direct |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Rated lifetime L70/B50 at 25 °C | 50000 Hour |
| Degree of protection (IP) | IP66 |
| Impact strength | IK08 |
| Protection class according to IEC 61140 | II |
| Emergency power supply integrated | No |
| Rated ambient temperature according to IEC 62722-2-1 | -20 - 50 Degrees celsius |
| Suitable for emergency lighting | No |
| With movement sensor | No |
| Luminaire efficacy | 76.5 Lumen/Watt |
| Rated luminous flux according to IEC 62722-2-1 | 840 Lumen |
| With light sensor | No |
| Covering of the luminaire with thermally insulating material possible | No |
| With air slots | No |
| Colour of light according to EN 12464-1 | Neutral white 3300-5300 K |
| Max. system power | 11 Watt |
| Colour of light | White |
| Colour temperature | 4200 Kelvin |
| Colour rendering index CRI | 80-89 |
| Power factor | 0.9 |
| Height/depth | 20 Millimetre |
| Outer diameter | 125 Millimetre |
| Built-in height/depth | 20 Millimetre |
| Built-in diameter | 105 Millimetre |
| Type of wiring | Ending |
| Connection type | Screwed terminal |
| Unified Glare Ratio (UGR) | 24 |
| Operation by Bluetooth | No |
