Prolumia LED Pro-Bay II Standard, 70W, 4000k 120 degree lens
| Serie: | Prolumia LED Pro-Bay II |
| Art. nr: | 40643011 |
| EAN: | 8720604745719 |
| User unit: | 1 PCE |
| Brand: | Prolumia |
| Type: | 40643011 |
| Manufacturer number: | 40643011 |
- Max. 150 Lm/W
- Waterproof LED luminaire (IP65)
- Zigbee (optional)
- Daylight sensor (in combination
- with Zigbee version)
Gross price (excl. VAT)
€ 334,00 Per 1 piece
€ 334,00 Per 1 piece
Raymond Sakko
Customer service
Do you have any questions?
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Our specialists are ready for you
Customer service: Call us on: 123456
Order: I want an account
Questions: start the live chat
Description
The LED Pro-Bay II is the new generation IP65 High-Bay luminaires. Application of medium power Nichia LEDs and a Mean Well driver results in a system efficiency up to 150 Lm/W. Application for great mounting heights is possible by using the available lenses and the wide range of armatures (max 300W). Using the Zigbee wireless communication, wireless switching and dimming is possible.Product features
| Subgroup | LED Pro-Bay II ⌀ 264 mm 70W |
| Brand | Prolumia |
| Mounting method | Surface mounting |
| Lamp type | LED not exchangeable |
| With light source | Yes |
| Suitable for number of light sources | 1 |
| Suitable for auxiliary lamp | No |
| Lamp holder | Other |
| Housing material | Aluminium |
| Housing colour | Black |
| Voltage type | AC |
| Nominal voltage | 240 Volt |
| Type of control gear | LED operating device voltage-controlled |
| Exchangeable control gear | No |
| With control gear | Yes |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming GPRS | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming DSI | No |
| Dimming phase cut-off (trailing edge) | No |
| Dimming phase cut-on (leading edge) | No |
| Dimming potentiometer (integrated) | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming programmable | No |
| No dim function | Yes |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Light distributor | Refractor lens |
| Light distribution | Symmetric |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Reflector | None |
| Material reflector | Without reflector (expired) |
| Beam angle | > 80° - Extreme wide beam |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Rated lifetime L70/B50 at 25 °C | 100000 Hour |
| Degree of protection (IP) | IP65 |
| Degree of protection (NEMA) | 3 |
| Impact strength | IK10 |
| Protection class according to IEC 61140 | II |
| Rated ambient temperature according to IEC 62722-2-1 | -30 - 50 Degrees celsius |
| Rated luminous flux according to IEC 62722-2-1 | 9800 Lumen |
| Luminaire efficacy | 140 Lumen/Watt |
| Suitable for emergency lighting | No |
| Max. system power | 70 Watt |
| Colour of light | White |
| Colour temperature | 3800 - 4200 Kelvin |
| Colour rendering index CRI | 70-79 |
| Total harmonic distortion | 20 |
| Power factor | 0.9 |
| Constant light output (CLO) | No |
| Colour of light adjustable | No |
| Beam angle adjustable | No |
| Luminous flux adjustable | No |
| Height/depth | 177 Millimetre |
| Outer diameter | 430 Millimetre |
| Type of wiring | Ending |
| Number of poles | 3 |
| Conductor cross section | 1.5 Square millimetre |
| Connection type | Other |
| With protective cover | Yes |
+ View all specifications
- Hide additional specifications
